Broach - Tang Hole Saw Blade for Knife Making
This tool from Nordic Edge is our version of the tang hole saw, or "broach".
A broach is used when fitting a stick tang blade into a handle block,
by rasping drilled holes into a slit or hole that matches the tang of the blade.
This is the broach blade only for those wanting to make their own custom handle.
The blade is made from stainless steel 5Cr15Mov, a tough and highly corrosion-resistant steel tempered to 56-57 HRC.
The blade is 162.8 mm long including the tang, and about 2.6 mm thick at the teeth.
The sharp section of the blade is about 96 mm x 2.6 mm with the Nordic Edge logo lasered on.
How to use the broach:
- accurately measure the tang of the blade where the handle will start
- scribe this onto the handle block
- drill a series of holes smaller than the marked area in a straight line
- use the broach to remove the handle material between the holes to create a slit
- rasp out the rest of the marked area, stopping often to test fit the blade
Why not practice by making a handle for the broach blade itself?
Broaches are not a new thing, most of us have some version of this already in our arsenal. Some use a short jigsaw blade fitted in a block of wood, others use a set of small files or wood rasps. This is just our take on the tool, with a blade narrow enough to get into holes 3 mm in diameter for fitting most blades except really thin chef blades, with agressive teeth for fast stock removal in wood and synthetic handle materials.
The Nordic Edge broach is designed by Nordic Edge in Australia and manufactured in China.
There is also a version with handle already made in maple wood, should you prefer to get it ready to use out of the box: LINK
Pro tip: When fitting a stick tang blade, using a carbide faced file guide to cut shoulders in the blade before fitting it makes for an even cleaner looking blade/handle fit. As the blade then has a shoulder to sit on, the tang hole can be made slightly narrower than the blade.
The Nordic Edge file guide is the original one with screw-down carbides, in stainless non-magnetic steel: LINK
This makes sure steel dust will not attach to it, neither will it rust in use from dunking in water.
Well packaged and Nordic Edges super fast postage. The broaches are very well made and sharp.
Top quality broach at a great price.
This is a great little tool, like how it has clean side edges to minimise side hole tear out, and only having teeth on the one side allows for less mistakes when when lifting and pulling the. Hole material out. Definitely worth having in the tool kit for any hidden tang knife maker
Its very good on softer timbers, I am using it in combination with another thinner blade which is sharper - combination is excellent on tough timbers- It doe pull more wood than the thinner blades,
